Plastic Shed Multi Span Greenhouse / Multi Span Agricultural
Polytunnel Greenhouse
Sawtooth Multispan Greenhouse:
The Top Saw Tooth model greenhouse combines optimal ventilation
with special strength for withstanding different loads. The roof
ventilation alone provides 25% of the total ventilation of the
covered area, in addition to the side ventilation. The shape of the
arches allows excellent light transmission.
Sawtooth Multispan Greenhouse Advantage:
Easy to assemble, cover and maintain
High roof opening for natural ventilation
Optimal heat and humidity release
Structure suitable for warm climate
Sawtooth Multispan Greenhouse Ventilation:
Natural ventilation system is the basic configuration of the
greenhouse, it can effectively make the indoor air to produce
natural convection. Through the electric or manually open the vents
to adjust the indoor temperature, humidity, and has a low operating
costs, easy to operate and so on.
Side Ventilation: Side open window roll ventilation and insect
net;Manual or electrical control; The ventilation is realized by
the film rolling up and down.
Top ventilation:Top open window roll ventilation and insect
net;Manual or electrical control;The ventilation is realized by the
chain rolling up and down.
Multispan Greenhouse Feature:
1) Various types of greenhouses have strong structures, suitable
for the development of modernization and high value-added
agriculture.
2) Excellent hot-dip galvanized steel structure and accessories,
corrosion resistance. 20-year service life.
3) PE film patented technology, well-known brand, guarantee 4-6
years service life.
4) Ventilation and pest control make your planting environment more
comfortable. increase output.
5) Cucumbers and tomatoes are generally more than 15,000 kilograms
per 1,000 square meters.
Multispan Greenhouse Parameter:
| Item | Parameter |
| Span | 8m /9m/10m /12m or customized |
| Width | 16m 24m 32m 40m 48m 56m or customized |
| Length | 16-60m or customized |
| Each Bay | 4m |
| Shoulder Height | 3m or customized |
| Total Height | 4.8-5.3m or customized |
| Covering material | PE film / Po (0.08 / 0.10 / 0.12 / 0.15 / 0.2mm) |
| Ventilation | Manual side ventilation / Manual roof ventilation / Electric side ventilation / roof ventilation |
Supporting system (choose according to your needs) | Cooling system & irrigation system & outside or inside shading system |
| The arch distance | 1.33m / 1.2 / 1.0 / 2.0 or customized |
| Arch diameter | 25mm, 32mm, 48mm or customized |
| Main Pillar | 50mm, 60mm, 76mm, 89mm, 114mm, 50X70mm, 60X80mm 50x100mm, 80x80mm, 100X100mm
Standard: 60mm, 50X70mm, 40x80mm, 80X80mm...etc |
| Steel tube thickness | 1.5mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm or customized |
| Foundation | Point concrete base |
Multispan Greenhouse Application:
It can be used for the seed-breeding and planting of flower and
vegetable, and the breeding of poultry.Besides.used as planting
vegetable and fruits, such Potato, tomato, cucumber, Onion, carrot,
zucchini, eggplant, okra, lettuce and so on.
